P3D Scaffolds
5 quick benefits
Explore our P3D Scaffolds - Standard Options
You will find a complete overview of our standard products below.
Choose design
Choose size & porosity
300-400 μm or 600-800 μm porosity
Choose plate solution
How to order
Fill out this form or email us at sales@ossiform.com to receive a quote from Ossiform. You can also purchase our products through the distributors linked below.
The scaffolds are supplied sterile and ready to use.
Easily apply 2D analysis methods.
Hassle-free handling.
Authorized P3D Scaffolds distributors
P3D Scaffolds set for 96-Well Plate
NB: only available in pore size 300-400 μm.
Choose between:
- Design: Gyroid or grid
- Size of your set: 48 or 96 scaffolds
Extra customizable product features:
- Scaffold height: 2-8 mm (Standard: 2 mm)
- Ultra clean (medical grade) β-tricalcium phosphate
P3D Scaffolds set for 24-Well Plate
Choose between:
- Design: Gyroid or grid
- Porosity: 300-400 μm or 600-800 μm
Extra customizable product features:
- Scaffold height: 2-8 mm (Standard: 3 mm)
- Ultra clean (medical grade) β-tricalcium phosphate
P3D Scaffolds set for 12-Well Plate
Choose between:
- Design: Gyroid or grid
- Porosity: 300-400 μm or 600-800 μm
Extra customizable product features:
- Scaffold height: 2-8 mm (Standard: 3 mm)
- Ultra clean (medical grade) β-tricalcium phosphate
P3D Scaffolds set for 6-Well Plate
Choose between:
- Design: Gyroid or grid
- Porosity: 300-400 μm or 600-800 μm
Extra customizable product features:
- Scaffold height: 2-8 mm (Standard: 3 mm)
- Ultra clean (medical grade) β-tricalcium phosphate
Extra customizable features
Special forms, sizes and designs of the 3D scaffolds can be requested for a fully customized set of cell culture systems.
Complementary products
Ultra Low Attachment Plates are also available for purchasing and highly recommended when using P3D Scaffolds.
Want assistance with your next
research project?
Patent status: The product is protected by one or more US, European, and/or foreign patents.
Disclaimer: The products are “For Research Use Only (RUO)” and should not be used for clinical purposes. Ossiform® makes no other warranties, expressed or implied, including the implied warranty of merchantability and the implied warranty of fitness for particular purpose.
Product overview
| SKU | Product description | Diameter x height | Porosity |
|---|---|---|---|
| DRL48GR1 | 48x grid scaffolds Ø5, small porosity | 5 mm x 2 mm | 300-400 μm |
| DRL48GY1 | 48x gyroid scaffolds Ø5, small porosity | 5 mm x 2 mm | 300-400 μm |
| DRL48GR2 | 48x grid scaffolds Ø5, large porosity | 5 mm x 2 mm | 600-800 μm |
| DRL48GY2 | 48x gyroid scaffolds Ø5, large porosity | 5 mm x 2 mm | 600-800 μm |
| DRL96GR1 | 96x grid scaffolds Ø5, small porosity | 5 mm x 2 mm | 300-400 μm |
| DRL96GY1 | 96x gyroid scaffolds Ø5, small porosity | 5 mm x 2 mm | 300-400 μm |
| DRL96GR2 | 96x grid scaffolds Ø5, large porosity | 5 mm x 2 mm | 600-800 μm |
| DRL96GY2 | 96x gyroid scaffolds Ø5, large porosity | 5 mm x 2 mm | 600-800 μm |
| DRL24GR1 | 24x grid scaffolds Ø12, small porosity | 12 mm x 3 mm | 300-400 μm |
| DRL24GY1 | 24x gyroid scaffolds Ø12, small porosity | 12 mm x 3 mm | 300-400 μm |
| DRL24GR2 | 24x grid scaffolds Ø12, large porosity | 12 mm x 3 mm | 600-800 μm |
| DRL24GY2 | 24x gyroid scaffolds Ø12, large porosity | 12 mm x 3 mm | 600-800 μm |
| DRL12GR1 | 12x grid scaffolds Ø20, small porosity | 20 mm x 3 mm | 300-400 μm |
| DRL12GY1 | 12x gyroid scaffolds Ø20, small porosity | 20 mm x 3 mm | 300-400 μm |
| DRL12GR2 | 12x grid scaffolds Ø20, large porosity | 20 mm x 3 mm | 600-800 μm |
| DRL12GY2 | 12x gyroid scaffolds Ø20, large porosity | 20 mm x 3 mm | 600-800 μm |
| DRL06GR1 | 6x grid scaffolds Ø30, small porosity | 30 mm x 3 mm | 300-400 μm |
| DRL06GY1 | 6x gyroid scaffolds Ø30, small porosity | 30 mm x 3 mm | 300-400 μm |
| DRL06GR2 | 6x grid scaffolds Ø30, large porosity | 30 mm x 3 mm | 600-800 μm |
| DRL06GY2 | 6x gyroid scaffolds Ø30, large porosity | 30 mm x 3 mm | 600-800 μm |
